| Place of Origin: | Korea |
|---|---|
| Brand Name: | PMC |
| Model Number: | GR46 |
| Minimum Order Quantity: | 1 PCS |
| Price: | USD180-200/PIECE |
| Packaging Details: | paper or customized |
| Delivery Time: | 2-3 days |
| Payment Terms: | T/T,Western Union,Money Gram |
| Supply Ability: | 1800pcs Per Month |
| Max Axial Load Static, KN: | 45 | Max Axial Load Dynamic, KN: | 25 |
|---|---|---|---|
| Torque (25MPa), Nm: | 1100 | Rated Displacement, Ml/r: | 20 |
| High Light: | 360 Degree Hydraulic Rotating Grapple,GR46 Rotating Grapple |
||
Quick Details :
We also provide the following models
|
Model
|
Rotation | MAX AXIAL LOAD STATIC,KN | MAX AXIAL LOAD DYNAMIC,KN | TORQUE (25MPa). Nm |
RATED DISPLACEMENT ML/R | WEIGHT KG |
| GR10 | Unlimited | 10 | 5 | 450 | 193 | 10 |
| GR30A | Unlimited | 30 | 15 | 900 | 330 | 16 |
| GR30B | Unlimited | 30 | 15 | 900 | 330 | 16 |
| GR30F | Unlimited | 30 | 15 | 900 | 330 | 22 |
| GR50 | Unlimited | 50 | 25 | 1400 | 465 | 28 |
| GR50F | Unlimited | 55 | 25 | 1400 | 465 | 33 |
| GR60 | Unlimited | 60 | 30 | 1800 | 670 | 45 |
| GR60-2 | Unlimited | 60 | 30 | 1800 | 670 | 47 |
| GR60F | Unlimited | 60 | 30 | 1800 | 678 | 48 |
| GR60F-2 | Unlimited | 60 | 30 | 1800 | 678 | 50 |
| GR100FD | Unlimited | +100/-80 | +50/-40 | 2700 | 871 | 64 |
| GR100FD-2 | Unlimited | +100/-80 | +50/-40 | 2700 | 871 | 67 |
| GR120FD | Unlimited | +120/-90 | +60/-45 | 2900 | 949 | 76 |
| GR120FD-2 | Unlimited | +120/-90 | +60/-45 | 2900 | 949 |
79
|
FAQ
Q1: What is your main market?
A: So far, we have exported our log grapples, hydraulic rotators…for worldwide, like Germany, France, Canada, Sweden, Australia
Q2: OEM is accepted?
A: Yes, of course!
Q3: How is your after-sale service?
A: We provice the good after-sale service. Time will prove it!
